Product Summary
The CS5336-KP is a complete analog-to-digital converter for stereo digital audio system. It performs sampling, analog-to-digital conversion and anti-aliasing filtering, generating 16-bit values for both left and right inputs in serial form. The output word rate can be up to 50 kHz per channel.
Parametrics
Absolute maximum ratings: (1)DC Power Supplies: -0.3V to +6.0 V; (2)Input Current, Any Pin Except Supplies: ± 10 mA max; (3)Analog Input Voltage (AIN and ZERO pins): (VA-)-0.3 V min and (VA+)+0.3 V max; (4)Digital Input Voltage: -0.3 V min and (VD+)+0.3 V max; (5)Storage Temperature: -55 to +125℃; (6)Ambient Temperature (power applied): -65 to +150℃.
Features
Features: (1)Complete CMOS Stereo A/D System; (2)Adjustable System Sampling Rates including 32kHz, 44.1 kHz & 48kHz; (3)Low Noise and Distortion >90 dB S/(N+D); (4)Internal 64X Oversampling; (5)Linear Phase Digital Anti-Alias Filtering; (6)Low Power Dissipation: 400 mW Power-Down Mode for Portable Applications; (7)Evaluation Board Available.
Diagrams
 |
