Product Summary
The CY7C346-35RMB is an Erasable Programmable Logic Device (EPLD) in which CMOS EPROM cells are used to configure logic functions within the device. The MAX architecture is 100% user-configurable, allowing the CY7C346-35RMB to accommodate a variety of independent logic functions. The 128 macrocells in the CY7C346-35RMB are divided into eight LABs, 16 per LAB. There are 256 expander product terms, 32 per LAB, to be used and shared by the macrocells within each LAB.
Parametrics
CY7C346-35RMB absolute maximum ratings: (1)Storage Temperature: –65 to+150℃; (2)Ambient Temperature with Power Applied: –55 to+125℃; (3)Maximum Junction Temperature (under bias): 150℃; (4)Supply Voltage to Ground Potential: –2.0V to +7.0V; (5)Maximum Power Dissipation: 2500 mW; (6)DC VCC or GND Current: 500 mA; (7)DC Output Current per Pin: –25 mA to +25 mA; (8)DC Input Voltage:–3.0V to +7.0V; (9)DC Program Voltage: 13.0V; (10)Static Discharge Voltage: > 1100V.
Features
CY7C346-35RMB features: (1)128 macrocells in eight logic array blocks (LABs); (2)20 dedicated inputs, up to 64 bidirectional I/O pins; (3)Programmable interconnect array; (4)0.8-micron double-metal CMOS EPROM technology; (5)Available in 84-pin CLCC, PLCC, and 100-pin PGA, PQFP.
Diagrams
 |
